Blow Molding Machines for Industrial Plastic Bottle & Container Production
Our industrial-grade blow molding machines are engineered for heavy-duty, 24/7 continuous hollow plastic production. Supporting a comprehensive range of Extrusion (EBM), Injection (IBM), and Stretch (SBM) blow molding technologies, our systems deliver stable cycle times, precise wall-thickness control, and optimized material efficiency for global packaging manufacturers.
-
Medicine Bottle Injection Blowing MachineThe Medicine Bottle Injection Machine is an integrated injection blow molding (IBM) system designed for high-precision production of pharmaceutical plastic bottles and medical packaging containers.Add to Inquiry -
Plastic Bottle Extrusion Blowing MachineThe Plastic Bottle Extrusion Blowing Machine is used for manufacturing hollow plastic containers through extrusion blow molding technology. It is widely applied in the production of bottles, jars,...Add to Inquiry -
Semi Automatic Injection Blowing Blow Molding MachineThe neck finish is fully completed during the Injection Stage under 140+ MPa pressure, achieving pharmaceutical-grade sealing surfaces. The bottle body is then finished in the Blow Stage via...Add to Inquiry -
Plastic Barrel Extrusion Blowing MachinePlastic Barrel Extrusion Blowing Machine is designed for manufacturers who need stable production of industrial packaging such as chemical drums, detergent barrels, lubricant containers, and other...Add to Inquiry
Bowing Molding Machine is a plastic processing machine. After the liquid plastic is sprayed out, the plastic body is blown and attached to the mold cavity of a certain shape by using the wind force blown out by the machine, so as to make the product. This machine is called blow molding machine. The plastic is melted and quantitatively extruded in the screw extruder, then formed through the mouth film, cooled by air ring blowing, then pulled by the tractor at a certain speed, and wound into a coil by the winder.
Bowing Molding Machine mostly adopts frequency converter, and the energy-saving way is to save the remaining energy consumption of the motor. It has the advantages of high thickness, corrosion resistance and wear resistance. The lifting unit adopts square frame platform structure, and the lifting frame height can be automatically adjusted according to different technical requirements. The unloading equipment adopts peeling rotating equipment and central rotating equipment, and the torque motor is used to adjust the smoothness of the film for easy operation.
Technical Specifications & Process Matrix
To match your specific container geometry and resin requirements, our machinery fleet is categorized into three specialized processing lines:
|
Machine Series |
Core Technology |
Target Containers & Volume Range |
Key Technical Feature |
|
Ex-Blow Series (EBM) |
Extrusion Blow Molding |
1L - 25L Jerry Cans, 200L L-Ring Drums, Toolboxes, IBC Tanks |
100-Point to 300-Point Parison Control; Up to 6-layer co-extrusion capability. |
|
Inject-Blow Series (IBM) |
Injection Blow Molding |
10ml - 500ml Pharmaceutical Vials, High-End Cosmetic Bottles |
Flash-free, scrap-free high-precision neck molding; Cleanroom class 100,000 compliant. |
|
Stretch-Blow Series (SBM) |
Stretch Blow Molding |
250ml - 5L PET Water & CSD Bottles, Edible Oil Jars |
High-speed linear or rotary infrared heating; Output up to 2,000 BPH per cavity. |
Key Engineering Features
Precision Parison Control
MOOG system with up to 100-point parison control, reducing weight by 10%–15% while maintaining strength.
Multi-Layer Co-Extrusion
1–6 layer die-head design, supports EVOH/PA barrier layers and recycled cores for cost and performance balance.
Servo-Hydraulic System
KEBA PLC with servo drive, delivers 30%–50% energy savings vs. conventional systems.
Rigid Clamping System
FEA-optimized structure ensures uniform clamping force, reduces flash, and extends mold life.
Industry Adaptations
Food & Beverage Packaging
All melt-contact components (screws, barrels, die heads) utilize non-contaminating, corrosion-resistant alloys, ensuring strict compliance with FDA and EU 10/2011 food-contact standards.
Pharmaceutical & Medical Containers
Our IBM and SBM platforms feature automated, oil-free clamping zones and enclosed layouts, easily adapting to ISO Class 8 (Class 100,000) cleanroom environments under strict GMP regulations.
Supply Chain & Quality Assurance Protocol
Premium Metallurgy for Abrasive Resins
Material Grade: Extruder screws and barrels are crafted from premium 38CrMoAlA structural alloy steel.
Surface Treatment: Finished with deep ion nitriding or optional bimetallic alloy coatings (Tungsten Carbide base) to withstand abrasive calcium carbonate masterbatches and high-percentage regrinds.
Strict Pre-Shipment Factory Acceptance Testing (FAT)
72-Hour Stress Test: Every machine undergoes a mandatory 72-hour continuous dry-cycle run and high-pressure hydraulic endurance check prior to dispatch.
Traceable Documentation: Complete FAT data sheets, component calibration logs, and operational video validations are archived and sent to the client 48 hours before loading.
Blow Molding Production Process
Material Conditioning
Resin is dried and homogenized inside a high-torque nitrided screw barrel to prevent thermal degradation.
01
Parison/Preform Generation
Molten polymer is extruded into a vertical tube (EBM) or injection-molded (IBM/SBM), regulated by dynamic wall-thickness programming.
02
High-Pressure Blowing
Heavy-duty clamping units lock the mold while clean, oil-free compressed air (up to 40 bar) inflates the plastic to its final shape.
03
Optimized Cooling
High-velocity cooling channels rapidly solidify the container, ensuring dimensional stability and minimizing cycle times.
04
Automated Deflashing
Finished parts are ejected, and flash/scraps are automatically trimmed and channeled to a granulator for closed-loop recycling.
05
Blow Molding Machine Buying Guide
Feasibility Analysis: Send us your 3D blueprints or samples. Our engineers analyze resin properties (MFI), volumetric tolerances, and top-load requirements.
Technology Routing: We match your product with the optimal platform—IBM for flash-free medical vials, SBM for high-speed PET bottles, or EBM for multi-layer barrier drums.
Output Calculation: We calculate required clamp tonnage and mold cavities based on your target volume to deliver clear hourly output and ROI projections.
2D/3D Plant Layout: We design full floor blueprints, optimizing the footprint of chillers, compressors, and automated conveyors to maximize space efficiency.
Customized Proposal: You receive a detailed engineering quote specifying custom screw geometries, parison controls, and automation upgrades tailored to your budget.
